JAVAD DELTA GNSS receiver

DELTA receiver is based on our TRIUMPH2/TRIUMPH Technology implemented in our TRIUMPH Chip. For the first time in the GNSS history we offer up to 100 Hz RTK.
864 channels of dual frequency GPS, Galileo, GLONASS, BeiDou, QZSS and IRNSS in a small attractive, sturdy, and watertight box, which contains either TRE-3, TRE-3N, or TRE-QUATTRO board.
216 channels chip is being utilized in DELTA, which contains either Duo-G2, Duo-G2D, TRE-G2T, or Quattro-G3D board.
The on-board power supply on DELTA receiver accepts any voltage from +10 to +30 volts and delivers clean filtered voltage where needed. This eliminates the risk of power contamination (ripples) that can be created when clean power is generated elsewhere and delivered to the board via cables. DELTA receiver also includes TriPad (two LEDs, ON/OFF and function button). In addition, the receiver comes with large amount of flash for data storage. The CAN interface in DELTA receiver is provided complete with all associated hardware and firmware, not just the CAN bus. The same is true with all the serial RS232/RS422 ports in our receiver. Simply stated, additional functions are not needed to incorporate any of our DELTA Receiver in most applications.
In addition to timing strobe and event marker, the DELTA receiver includes the option of complete IRIG timing system.

Signals received Gps, Galileo, GLONASS, BeiDou, QZSS and IRNSS
Number of channels 864
External antenna type
Body material Aluminum extrusion, waterproof IP66
Weight 0.595 kg
Post-processing accuracy 3 mm + 0.5 ppm
RTK accuracy 10 mm + 0.5 ppm
Raw data recording Up to 100 Hz
Memory 2048 MB
Operating temperature -40 ° C to + 80 ° C
Dimensions 109 x 35 x 141 / max 160 with connectors
Protection against dust and water 66 IP
RTK Base and Rover mode
