REACH M2/M+

RTK GNSS modules
for UAV mapping
Positioning with centimeter accuracy in RTK and PPK.
For precise UAV mapping with less GCP

Why camera synchronization is so important
Usually autopilot triggers the camera and records the coordinate it has at that moment. When the drone is flying at 20 m/s and GPS works at 5 Hz, that means your autopilot will have position readings only each 4 m, which is not suitable for precise georeferencing. In addition, there is always a delay between the trigger and the actual moment the photo is taken.

Reach eliminates the delay
Reach solves the problem of positioning by connecting directly to the camera hot shoe port, which is synced with the shutter. The time and coordinates of each photo are logged with a resolution of less than a microsecond. This method allows GCPs to be used only to check your accuracy.

NTRIP or another Reach as a base station
To calculate centimeter-precise coordinates in PPK and RTK, Reach needs corrections from a base station. It could be either another Reach receiver or an NTRIP service. VRS is also supported.

Compatibility

Reach M2 and M+ work seamlessly with other Reach receivers over any link and are compatible with any other receiver that supports RTCM3 and NTRIP.

Choosing between
Reach M+ and Reach M2

Reach M+
and Reach RS+

If you work within short baselines, then Reach M+ is an optimal choice.

Reach M2
and Reach RS2

Provides robust performance and quick initialization, allowing work on long baselines.

RTK
Up to 10 km
Up to 60 km

PPK
Up to 20 km
Up to 100 km

Time to fix
1-2 min
5 sec

Frequency bands
Single-band

Multi-band

RINEX logging update rate
Up to 14 Hz
Up to 20 Hz*

*coming with a software update,
up to 10 Hz now

REACH M2

Mechanical
Dimensions56.4 x 45.3 x 14.6 mm
Weight35 g
Operating tº-20…+65 ºC

Electrical
Input voltage on USB and JST GH4.75 - 5.5 V
Antenna DC bias3.3 V
Avg. consumption @5V200 mA

Positioning
Static horizontal4 mm + 0.5 ppm
Static vertical8 mm + 1 ppm
Kinematic horizontal7 mm + 1 ppm
Kinematic vertical14 mm + 1 ppm

Connectivity
LoRa radio (sold separately)
Frequency range868/915 MHz
DistanceUp to 8 km
Wi-Fi802.11b/g/n
Bluetooth4.0/2.1 EDR
PortsUSB, UART, Event

Data
CorrectionsNTRIP, VRS, RTCM3
Position outputNMEA, LLH/XYZ
Data loggingRINEX with events
with update rate up to 20 Hz*
*coming with a software update,
up to 10 Hz now
Internal storage16 GB

GNSS
Signal trackedGPS/QZSS L1C/A, L2C
GLONASS L1OF, L2OF
BeiDou B1I, B2I
Galileo E1-B/C, E5b
Number of channels184
Update rates20 Hz* GPS / 10 Hz GNSS
*coming with a software update,
up to 10 Hz now
IMU9DOF

REACH M+
Mechanical
Dimensions56.4 x 45.3 x 14.6 mm
Weight35 g
Operating tº-20…+65 ºC

Electrical
Input voltage on USB and JST GH4.75 - 5.5 V
Antenna DC bias3.3 V
Avg. consumption @5V200 mA

Positioning
Static horizontal5 mm + 1 ppm
Static vertical10 mm + 2 ppm
Kinematic horizontal7 mm + 1 ppm
Kinematic vertical14 mm + 2 ppm

Connectivity
LoRa radio (sold separately)
Frequency range868/915 MHz
DistanceUp to 8 km
Wi-Fi802.11b/g/n
Bluetooth4.0/2.1 EDR
PortsUSB, UART, Event

Data
CorrectionsNTRIP, VRS, RTCM3
Position outputNMEA, LLH/XYZ
Data loggingRINEX with events
with update rate up to 14 Hz
Internal storage8 GB

GNSS
Signal trackedGPS/QZSS L1, GLONASS G1,
BeiDou B1, Galileo E1, SBAS
Number of channels72
Update rates14 Hz / 5 Hz
IMU9DOF
